Tegtal
Yonnee nga laaj
Kodu komànd
|
Royuwaay
|
4V310-08
4V320-08 |
4V330C-08
4V330E-08 4V330P-08 |
4V310-10
4V320-10 |
4V330C-10
4V330E-10 4V330P-10 |
|
Rogalaan
|
Air(ngir segg ko ci 40μm element filtre)
|
|||
|
Jëf
|
Pilot bi ci biir wala pilote bi ci biti
|
|||
|
Port[Net1]
|
Ci=P
|
Ci=Out{1}/8"Exhaust{3"
|
||
|
Dayo bu wuute
|
25.0mm2
({0}}) |
18.0mm2
({0}}) |
30.0mm2
({0}}) |
18.0mm2
({0}}) |
|
Xeetal xeetu
|
5 port 2 position
|
5 port 3 position
|
5 port 2 position
|
5 port 3 position
|
|
Pression bi ngay def
|
0.15~0.8MPa(21~114psi)
|
|||
|
Firnde
|
1.2MPa(175psi)
|
|||
|
Tàngooru yaram
|
-20~ 70 degre
|
|||
|
Materiyelu yaram
|
Aluminium
|
|||
|
Lubrication [Note2]
|
soxlawul
|
|||
|
Max.frequency [Net3]
|
4 cycle/sec
|
3 cycle/sec
|
4 cycle/sec
|
3 cycle/sec
|
|
Yomb (g)
|
4V310-08:310
4V320-08:400 |
450
|
4V310-10:310
4V320-10:400 |
450
|
Melo jëmmal:
1.Pilot {1} mode à mode: pilote bi ci biir wala ci biti.
2. Structure ci mode kolonn: métage bu baax ak reaction de démb .
3. Ñaar position solenoid amna ñatti xeeti central funfunction ngir sa tànneef.
4. Ndax vanne solenoid bi ngay saytu amna fonction memory
5. pax mi ci biir dafay jël xaralay liggéey bu amul benn werante, te amul benn friction, tàmbali di tàmbali ak dundu liggéey bu yàgg.
6. Soxlawoo diw ngir am lubrifiant.
7.l mën nañu ko sos ngir sos kuréel vanne buñ boole mu am bayaal buy denc ba noppi di denc bayaal bi.
8. Aparey yi ñuy jëfandikoo ngir mëna def ay mbir ngir mëna yombal ak debugging.
9. Njàngat yu bari ci voltage bi mën nañu ko jëfandikoo.
